• Metal Wire Drawing：Cold,Hot Drawing
• Status：Soft State
• Thickness：Metal Microfilament
• Wire Diameter：0.018-0.5mm
• Transport Package：as Your Request
• Specification：304 304L 316 316L etc.
• Trademark：weiyue
• Origin：Hebei, Anping
• HS Code：7229901000
• Production Capacity：600 Metric Ton ,Month

Basic Info.

Metal Wire Drawing Cold/Hot Drawing Status Soft State Thickness Metal Microfilament Wire Diameter 0.018-0.5mm Transport Package as Your Request Specification 304 304L 316 316L etc. Trademark weiyue Origin Hebei, Anping HS Code 7229901000 Production Capacity 600 Metric Ton /Month

Product Description

Material:304 304L 316 316L etc.
Diameter:0.018mm to 0.05mm
Stainless steel wire application
(1) Tools: tie wire, pins, lashing, forming wire, filters,, gaskets, safety wire .etc.
(2) Fittings: weaving woven wire mesh, conveyors, jewelry, springs, wire line, bicycle fittings,
craft fittings .etc
(3) Goods: kitchen tools, sanitation tools, goods shelf, pet cages, gill racks, and baskets .etc
(4) Food and medical machinery accessories.

Spools: Under normal circumstances, we are the following five specifications, but according to customer requirements for the production of other spools.

	HK100	HK115	K90*100	PL-1	KK80
D1	100	115	90	80	80
D2	74	88	60	60	53
D3	25	25	20	20	20
L1	160	140	120	120	100
L2	85	80	100	100	70
Weight(g)	274	280	100	76	82

Our products strength and elongation.

material	Wire Dia.(mm)	strength(mpa)	EL(%)	SWG	AWG	Inch	Allow difference  (mm)
316L	0.035	570-800	≥22		AWG 47	0.00138	+0.002  -0.001
316L	0.04	550-800	≥23	SWG 48	AWG 46	0.00158	+0.002  -0.001
316L	0.05	680-850	≥24	SWG 47	AWG 44	0.00197	±0.002
